Edelbrock Rollin' Thunder Camshaft #2209 is designed for 265-350 Chevy V8 engines from 1987-Later and produce optimum torque from the low-end to the mid-range. Rollin' Thunder camshafts should be matched with Performer manifolds for vehicles operating from off-idle to 5500 rpm. They are smooth idling cams for daily drivers, trucks, vans, RVs and 4x4s. You can expect a major improvement in throttle response and torque. In the manifold section you'll find torque graphs showing the power gains from Performer manifolds and Performer-Plus cams. All camshafts include flat tappet lifters (except for cams designed for use with stock roller lifters), assembly lube and instructions. This cam produced 408HP and 450 Ft Lbs or Torque when paired with Pro-Flo XT EFI system #3528 and Performer RPM E-Tec cylinder heads #60975 on a 383 c.i.d. engine using stock hydraulic roller lifters and pushrods. Camshaft specifications: - Intake duration: 212 Degrees - Exhaust duration: 222 Degrees - Intake lift: .462" - Exhaust lift: .479" - Lobe separation: 112 Degree - Intake Center Line: 107 Degree - Vacuum: 16"
Technical Bulletin
Installation Instructions
Installation Instructions
Installation Instructions
This Part Fits:
Technical Bulletin
Installation Instructions
Installation Instructions
Installation Instructions
This Part Fits:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 1991-1993 | Buick | Commercial Chassis | Base |
| 1992-1993 | Buick | Roadmaster | Base |
| 1991-1993 | Buick | Roadmaster | Estate Wagon |
| 1992-1993 | Buick | Roadmaster | Limited |
| 1990-1992 | Cadillac | Brougham | Base |
| 1990-1992 | Cadillac | Brougham | d'Elegance |
| 1994-1996 | Cadillac | Commercial Chassis | Base |
| 1992-1996 | Cadillac | Commercial Chassis | Brougham |
| 1993-1996 | Cadillac | Fleetwood | Base |
| 1993-1996 | Cadillac | Fleetwood | Brougham |
| 1994 | Chevrolet | Blazer | Base |
| 1992-1993 | Chevrolet | Blazer | Cheyenne |
| 1987 | Chevrolet | Blazer | Custom Deluxe |
| 1988-1991 | Chevrolet | Blazer | Scottsdale |
| 1987-1994 | Chevrolet | Blazer | Silverado |
| 1994 | Chevrolet | Blazer | Silverado Sport |
| 1994-1995 | Chevrolet | C1500 | Base |
| 1988-1995 | Chevrolet | C1500 | Cheyenne |
| 1988-1992 | Chevrolet | C1500 | Scottsdale |
| 1988-1995 | Chevrolet | C1500 | Silverado |
| 1990-1995 | Chevrolet | C1500 | WT |
| 1992-1995 | Chevrolet | C1500 Suburban | Base |
| 1995 | Chevrolet | C1500 Suburban | LS |
| 1995 | Chevrolet | C1500 Suburban | LT |
| 1992-1994 | Chevrolet | C1500 Suburban | Silverado |
| 1994-1995 | Chevrolet | C2500 | Base |
| 1988-1995 | Chevrolet | C2500 | Cheyenne |
| 1988-1992 | Chevrolet | C2500 | Scottsdale |
| 1988-1995 | Chevrolet | C2500 | Silverado |
| 1994-1995 | Chevrolet | C2500 | WT |
| 1992-1995 | Chevrolet | C2500 Suburban | Base |
| 1995 | Chevrolet | C2500 Suburban | LS |
| 1995 | Chevrolet | C2500 Suburban | LT |
| 1992-1994 | Chevrolet | C2500 Suburban | Silverado |
| 1994-1995 | Chevrolet | C3500 | Base |
| 1988-1995 | Chevrolet | C3500 | Cheyenne |
| 1988-1992 | Chevrolet | C3500 | Scottsdale |
| 1988-1995 | Chevrolet | C3500 | Silverado |
| 1988 | Chevrolet | Camaro | Base |
| 1987-1990 | Chevrolet | Camaro | Iroc-Z |
| 1987 | Chevrolet | Camaro | LT |
| 1989-1992 | Chevrolet | Camaro | RS |
| 1992 | Chevrolet | Camaro | RS Heritage Edition |
| 1987 | Chevrolet | Camaro | Sport |
| 1987,1991-1992 | Chevrolet | Camaro | Z28 |
| 1992 | Chevrolet | Camaro | Z28 Heritage Edition |
| 1987-1992 | Chevrolet | Caprice | Base |
| 1987-1996 | Chevrolet | Caprice | Classic |
| 1987-1990 | Chevrolet | Caprice | Classic Brougham |
| 1993-1994 | Chevrolet | Caprice | Classic LS |
| 1987-1990 | Chevrolet | Caprice | Classic LS Brougham |
| 1991-1993 | Chevrolet | Caprice | Classic LTZ |
| 1991-1993 | Chevrolet | Commercial Chassis | Base |
| 1988 | Chevrolet | Corvette | 35th Anniversary Edition |
| 1987-1991 | Chevrolet | Corvette | Base |
| 1987 | Chevrolet | El Camino | Base |
| 1987 | Chevrolet | El Camino | SS |
| 1987-1995 | Chevrolet | G10 | Beauville |
| 1987 | Chevrolet | G10 | Bonaventure |
| 1987-1995 | Chevrolet | G10 | Chevy Van |
| 1987-1995 | Chevrolet | G10 | Sportvan |
| 1987-1995 | Chevrolet | G20 | Beauville |
| 1987-1995 | Chevrolet | G20 | Chevy Van |
| 1987-1995 | Chevrolet | G20 | Sportvan |
| 1987-1996 | Chevrolet | G30 | Beauville |
| 1987-1996 | Chevrolet | G30 | Chevy Van |
| 1987-1996 | Chevrolet | G30 | Hi-Cube |
| 1987-1996 | Chevrolet | G30 | Sportvan |
| 1994-1995 | Chevrolet | K1500 | Base |
| 1988-1995 | Chevrolet | K1500 | Cheyenne |
| 1988-1992 | Chevrolet | K1500 | Scottsdale |
| 1988-1995 | Chevrolet | K1500 | Silverado |
| 1991 | Chevrolet | K1500 | Sport |
| 1990-1995 | Chevrolet | K1500 | WT |
| 1992-1995 | Chevrolet | K1500 Suburban | Base |
| 1995 | Chevrolet | K1500 Suburban | LS |
| 1995 | Chevrolet | K1500 Suburban | LT |
| 1992-1994 | Chevrolet | K1500 Suburban | Silverado |
| 1994-1995 | Chevrolet | K2500 | Base |
| 1988-1995 | Chevrolet | K2500 | Cheyenne |
| 1988-1992 | Chevrolet | K2500 | Scottsdale |
| 1988-1995 | Chevrolet | K2500 | Silverado |
| 1994-1995 | Chevrolet | K2500 | WT |
| 1992-1995 | Chevrolet | K2500 Suburban | Base |
| 1995 | Chevrolet | K2500 Suburban | LS |
| 1995 | Chevrolet | K2500 Suburban | LT |
| 1992-1994 | Chevrolet | K2500 Suburban | Silverado |
| 1994-1995 | Chevrolet | K3500 | Base |
| 1988-1995 | Chevrolet | K3500 | Cheyenne |
| 1988-1992 | Chevrolet | K3500 | Scottsdale |
| 1988-1995 | Chevrolet | K3500 | Silverado |
| 1987-1988 | Chevrolet | Monte Carlo | Base |
| 1987-1988 | Chevrolet | Monte Carlo | LS |
| 1987-1988 | Chevrolet | Monte Carlo | SS |
| 1987 | Chevrolet | R10 | Custom Deluxe |
| 1987 | Chevrolet | R10 | Scottsdale |
| 1987 | Chevrolet | R10 | Silverado |
| 1987 | Chevrolet | R10 Suburban | Custom Deluxe |
| 1987-1988 | Chevrolet | R10 Suburban | Scottsdale |
| 1987-1988 | Chevrolet | R10 Suburban | Silverado |
| 1989-1991 | Chevrolet | R1500 Suburban | Scottsdale |
| 1989-1991 | Chevrolet | R1500 Suburban | Silverado |
| 1988 | Chevrolet | R20 | Cheyenne |
| 1987-1988 | Chevrolet | R20 | Custom Deluxe |
| 1987-1988 | Chevrolet | R20 | Scottsdale |
| 1987-1988 | Chevrolet | R20 | Silverado |
| 1987 | Chevrolet | R20 Suburban | Custom Deluxe |
| 1987-1988 | Chevrolet | R20 Suburban | Scottsdale |
| 1987-1988 | Chevrolet | R20 Suburban | Silverado |
| 1989 | Chevrolet | R2500 | Silverado |
| 1989-1991 | Chevrolet | R2500 Suburban | Scottsdale |
| 1989-1991 | Chevrolet | R2500 Suburban | Silverado |
| 1988 | Chevrolet | R30 | Cheyenne |
| 1987-1988 | Chevrolet | R30 | Custom Deluxe |
| 1987-1988 | Chevrolet | R30 | Scottsdale |
| 1987-1988 | Chevrolet | R30 | Silverado |
| 1989-1991 | Chevrolet | R3500 | Cheyenne |
| 1989-1990 | Chevrolet | R3500 | Scottsdale |
| 1989-1991 | Chevrolet | R3500 | Silverado |
| 1995 | Chevrolet | Tahoe | Base |
| 1995 | Chevrolet | Tahoe | LS |
| 1995 | Chevrolet | Tahoe | LT |
| 1987 | Chevrolet | V10 | Custom Deluxe |
| 1987 | Chevrolet | V10 | Scottsdale |
| 1987 | Chevrolet | V10 | Silverado |
| 1987 | Chevrolet | V10 Suburban | Custom Deluxe |
| 1987-1988 | Chevrolet | V10 Suburban | Scottsdale |
| 1987-1988 | Chevrolet | V10 Suburban | Silverado |
| 1989-1991 | Chevrolet | V1500 Suburban | Scottsdale |
| 1989-1991 | Chevrolet | V1500 Suburban | Silverado |
| 1987 | Chevrolet | V20 | Custom Deluxe |
| 1987 | Chevrolet | V20 | Scottsdale |
| 1987 | Chevrolet | V20 | Silverado |
| 1987 | Chevrolet | V20 Suburban | Custom Deluxe |
| 1987-1988 | Chevrolet | V20 Suburban | Scottsdale |
| 1987-1988 | Chevrolet | V20 Suburban | Silverado |
| 1989-1991 | Chevrolet | V2500 Suburban | Scottsdale |
| 1989-1991 | Chevrolet | V2500 Suburban | Silverado |
| 1988 | Chevrolet | V30 | Cheyenne |
| 1987-1988 | Chevrolet | V30 | Custom Deluxe |
| 1987-1988 | Chevrolet | V30 | Scottsdale |
| 1987-1988 | Chevrolet | V30 | Silverado |
| 1989-1991 | Chevrolet | V3500 | Cheyenne |
| 1989-1990 | Chevrolet | V3500 | Scottsdale |
| 1989-1991 | Chevrolet | V3500 | Silverado |
| 1993 | Excalibur | Limited | Base |
| 1987-1989 | Excalibur | Phaeton | Base |
| 1988-1993 | GMC | C1500 | Sierra |
| 1994-1995 | GMC | C1500 | Sierra SL |
| 1988-1995 | GMC | C1500 | Sierra SLE |
| 1994-1995 | GMC | C1500 | Sierra SLT |
| 1988-1993 | GMC | C1500 | Sierra SLX |
| 1994-1995 | GMC | C1500 | Sierra Special |
| 1992-1995 | GMC | C1500 Suburban | Base |
| 1992-1995 | GMC | C1500 Suburban | SLE |
| 1995 | GMC | C1500 Suburban | SLT |
| 1988-1993 | GMC | C2500 | Sierra |
| 1994-1995 | GMC | C2500 | Sierra SL |
| 1988-1995 | GMC | C2500 | Sierra SLE |
| 1994-1995 | GMC | C2500 | Sierra SLT |
| 1988-1993 | GMC | C2500 | Sierra SLX |
| 1992-1995 | GMC | C2500 Suburban | Base |
| 1992-1995 | GMC | C2500 Suburban | SLE |
| 1995 | GMC | C2500 Suburban | SLT |
| 1988-1993 | GMC | C3500 | Sierra |
| 1994-1995 | GMC | C3500 | Sierra SL |
| 1988-1995 | GMC | C3500 | Sierra SLE |
| 1994-1995 | GMC | C3500 | Sierra SLT |
| 1988-1993 | GMC | C3500 | Sierra SLX |
| 1987 | GMC | Caballero | Base |
| 1987 | GMC | Caballero | Diablo |
| 1987-1995 | GMC | G1500 | Rally |
| 1987-1995 | GMC | G1500 | Rally STX |
| 1987-1995 | GMC | G1500 | Vandura |
| 1987-1995 | GMC | G2500 | Rally |
| 1987-1995 | GMC | G2500 | Rally STX |
| 1987-1995 | GMC | G2500 | Vandura |
| 1987-1996 | GMC | G3500 | Magnavan |
| 1987-1996 | GMC | G3500 | Rally |
| 1987-1995 | GMC | G3500 | Rally Camper Special |
| 1987-1988 | GMC | G3500 | Rally Custom |
| 1987-1996 | GMC | G3500 | Rally STX |
| 1987-1996 | GMC | G3500 | Vandura |
| 1987-1995 | GMC | G3500 | Vandura Special |
| 1987-1991 | GMC | Jimmy | Base |
| 1987-1990 | GMC | Jimmy | Sierra Classic |
| 1988-1993 | GMC | K1500 | Sierra |
| 1994-1995 | GMC | K1500 | Sierra SL |
| 1988-1995 | GMC | K1500 | Sierra SLE |
| 1995 | GMC | K1500 | Sierra SLS |
| 1994-1995 | GMC | K1500 | Sierra SLT |
| 1988-1993 | GMC | K1500 | Sierra SLX |
| 1994-1995 | GMC | K1500 | Sierra Special |
| 1993 | GMC | K1500 | Sierra Sport |
| 1992-1995 | GMC | K1500 Suburban | Base |
| 1992-1995 | GMC | K1500 Suburban | SLE |
| 1995 | GMC | K1500 Suburban | SLT |
| 1988-1993 | GMC | K2500 | Sierra |
| 1994-1995 | GMC | K2500 | Sierra SL |
| 1988-1995 | GMC | K2500 | Sierra SLE |
